Specialized single-piece fan-shaped nozzle for sandblasting machines, made of ultra-high molecular weight polyethylene (UPE) for an extended lifespan and reduced maintenance costs.
A sandblasting nozzle in sandblasting machines uses high-pressure air to propel abrasives onto surfaces. Adjusting abrasive type, air pressure, spray distance, and angle tailors the effect. It removes paint and rust, roughens surfaces, and enhances friction or adhesion for coating or bonding.
A flat fan nozzle works by forcing liquid through an oval-shaped orifice, spreading it into a fan shape. This design provides strong central flow and weaker edges, ideal for uniform coverage in industries like semiconductors, PCB manufacturing, and steel. It offers precise control, resists clogging, and delivers high impact force.
A single-fluid fan spray nozzle produces a spray pattern resembling a fan, hence the name. The coverage pattern, when viewed from above the target area, forms a single-line shape with tapered edges on both sides. Learn more : Nozzle Spray Pattern
The fan spray nozzle has maximum spray volume in the center, decreasing towards the edges, forming a mound-shaped distribution. Ideal for concentrated impact applications like surface cleaning. For uniform spraying, install nozzles closer together to overlap coverage areas and improve uniformity. Learn more : Nozzle Flow Distribution
The fan spray nozzle provides various angle options, with 0° producing a straight jet for maximum impact, and 110° offering the widest coverage. For specific inventory details, please contact us.
This nozzle attaches to pipelines directly. Usage time and environment impact spray performance (flow and angle). Regular maintenance or replacement needed. For tougher conditions, we have a quick-release multi-piece nozzle for easy replacement, saving time and effort.
Cut from ultra-high molecular weight UPE rods, Ideal for applications with solid particles in liquids, requiring high wear resistance, and offering longer-lasting performance compared to stainless steel and ceramics.
LORRIC UPE nozzles offer a symmetrical spray distribution, ensuring seamless and complete coverage with standard nozzle arrangements. This uniform distribution results in even chemical reactions. In contrast, lower-quality nozzles available in the market may have uneven spray distribution, causing gaps in the spraying pattern and failing to achieve the desired effectiveness, ultimately leading to wastage of chemicals.
The flow tolerance is within a range of plus or minus 5% of the standard flow rate.
Angle tolerance is within a range of plus or minus 5% of the standard angle.
We take high quality smithing metal to produce solid and durable nozzles by detail turning.
We promise never to use recycled materials.
All material is purchased from world top providers.
UPE nozzles are commonly used in sandblasting machines, which are part of a wet sandblasting process. This equipment can spray abrasive material (12% steel grit, 88% water) as a mist onto the surface of printed circuit boards, ensuring good adhesion and creating a uniformly non-directional ideal surface condition. As a result, it is effective for various pre-treatment processes such as dry film pre-treatment, pre-soldering treatment, pre-metal plating treatment, and liquid solder resist pre-treatment. Due to the significant wear and frequent replacement of nozzles in wet sandblasting processes, LORRIC's products have a longer lifespan compared to lower-quality competitors. They can improve nozzle longevity by 2 to 4 times, effectively reducing the yield loss caused by nozzle hole enlargement. This, in turn, lowers downtime and labor costs associated with nozzle replacements, helping achieve cost reduction objectives.
Easy installing with 2 simple steps!
Please ensure that the nozzle size matches the thread size on the pipes.
Apply Teflon tape, tighten nozzle clockwise for no leaks.
Complete the installation.
With over 30 years of nozzle development and manufacturing experience, along with extensive customer site knowledge, allow us to assist in creating the ideal product for your needs!
LORRIC can customize "flow rate," "angle," and "flow distribution" to suit your specific usage scenarios. We also offer support for unique situations like special impact force or ultra-fine spray needs. Feel free to reach out to LORRIC's team for more information and assistance.
Under fixed pressure, the volume of liquid or gas sprayed by nozzles within a certain period of time.
It is the angle by orifice and the loop of gas or liquid sprayed out.
The distribution of particle on surface by sprayed up liquid.
Testing in extreme environments demands data to aid nozzle development.
